Typical lifting time: 20 seconds to maximum height of 60”
Maximum lifting height: 60” (1.52m)
Crank force required: 5 lbs to lift 150 lbs, 11 lbs to lift 300 lbs
Capacity: 600 lbs (275kg)
Lift weight: 265 lbs. (120 kg)
Lift height: 66” (1.67m)
Lift width: 37.5” (0.95m)
Length: 72” (1.83m)
Platform size: 34” X 56” (0.86m X 1.42m)
​Bridge ramp size: Accommodates a large wheelchair or scooter 20”L X 32”W (0.51m X 0.81m)
